This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
Sale
{{ item.Quote }}
Break out of the box and expand your road riding adventures. From smooth pavement to bumpy backroads, this ultra-capable road bike has built-in compliance and high-volume tyres, so you can ride any road with confidence and control.
Key Performance Factors
Balanced road geometry
Frame is specifically engineered to produce a balanced, all-rounder feel that blends confident rider positioning with agile cornering and acceleration.
Smooth ride quality
Innovative D-Fuse seatpost reduces road shocks and vibrations, and a Giant WheelSystem lets you run tubeless tyres* up to 38mm for a smoother ride quality and reduced risk of flats. *On selected models
Total control
Seamless disc brake integration, including flat mounts and 12mm front and rear thru-axles, produces more consistent braking power for better control, even in wet weather and on rough roads.
Techs & Features
ALUXX Aluminium Technology
D-Fuse Technology
The D-Fuse seatpost and handlebar were designed to function as a system, absorbing road shocks and vibrations so you can ride further, faster.
OverDrive
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Compact Road Design
Introduced by Giant with the professional Team ONCE in the 1990s, Compact Road revolutionized the look and feel of high-performance road bikes forever. A downward sloping toptube (from the headtube to the seattube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.
Tubeless System
Fewer flat tyres. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
Sizing Guide and Geometry
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- XS
- 157 cm5’2”
169 cm5’7”
- S
- 165 cm5’5” 175 cm5’9”
- M
- 171 cm5’7” 181 cm5’11”
- ML
- 177 cm5’10” 187 cm6’2”
- L
- 183 cm6’0” 193 cm6’4”
- XL
- 189 cm6’2” 199 cm6’6”
| XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 43016.9 | 46518.3 | 50019.7 | 53521.1 | 55521.9 | 58523 |
| B | Seat Tube Angle (degrees) | 75.0° | 74.0° | 73.5° | 73.0° | 73.0° | 73.0° |
| C | Top Tube Length (mm) (inch) | 51520.3 | 53521.1 | 55021.7 | 56522.2 | 58022.8 | 59523.4 |
| D | Head Tube Length (mm) (inch) | 1154.5 | 1355.3 | 1505.9 | 1706.7 | 1907.5 | 2158.5 |
| E | Head Tube Angle (degrees) | 71.5° | 71.8° | 72.0° | 72.5° | 72.5° | 72.5° |
| F | Fork Rake (mm) (inch) | 532.1 | 532.1 | 532.1 | 532.1 | 532.1 | 532.1 |
| G | Trail (mm) (inch) | 62.92.4 | 61.32.4 | 59.62.3 | 56.42.2 | 56.42.2 | 56.42.2 |
| H | Wheelbase (mm) (inch) | 99439.1 | 100339.5 | 101139.8 | 101540 | 103140.6 | 104641.2 |
| I | Chain Stay Length (mm) (inch) | 42216.6 | 42216.6 | 42216.6 | 42216.6 | 42216.6 | 42216.6 |
| J | Bottom Bracket Drop (mm) (inch) | 803.1 | 803.1 | 803.1 | 803.1 | 803.1 | 803.1 |
| K | Stack (mm) (inch) | 53921.2 | 55922 | 57422.6 | 59523.4 | 61424.2 | 63825.1 |
| L | Reach (mm) (inch) | 37114.6 | 37514.8 | 38015 | 38315.1 | 39215.4 | 40015.7 |
| M | Stand Over Height (mm) (inch) | 72728.6 | 75929.9 | 78330.8 | 81031.9 | 82932.6 | 85633.7 |
| O | Stem Length (mm) (inch) | 803.1 | 903.5 | 1003.9 | 1003.9 | 1104.3 | 1104.3 |
| P | Crank Length (mm) (inch) | 1706.7 | 1706.7 | 172.56.8 | 172.56.8 | 1756.9 | 1756.9 |
| Q | Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
